3D Scanners
Digitise 3D Objects
3D Scanning is the process implemented to collect data of a three-dimensional object or environment. This data is then analysed and reconstructed and results is a 3D digital file which can then be edited and reproduced via manufacturing mediums.
A 3D scanner can be based on many different technologies, each with its own limitations, advantages, and costs. Many limitations in the kind of objects that can be digitised are still present. for example, optical technology (such as the EinScan) may encounter many difficulties with shiny, reflective, or transparent objects.
Required Badge
Suitable Materials
Process
- 3D Scanning
Machine Locations
| Makerspace | Facility | Make | Model | Work area | Number of machines |
|---|---|---|---|---|---|
| Engineering Makerspaces | Elec Makerspace | Artec 3D | Spider II | Objects 5-50cm, 0.05mm Resolution, tethered handheld | 1 |
| Engineering Makerspaces | Elec Makerspace | Shining 3D | EinScan Pro 2X | Objects 15-80cm, 0.1mm resolution, tethered handheld | 1 |
| Engineering Makerspaces | Elec Makerspace | Shining 3D | EinScan-SE | Objects 3-20cm, 0.1mm resolution, with turntable | 2 |
| MCIC | MCIC Makerspace | Artec 3D | Leo | Objects 20-200cm, 0.2mm Resolution, standalone handheld | 1 |
| MCIC | MCIC Makerspace | Artec 3D | Micro II | Objects <5-20cm, 40µm resolution, desktop | 1 |
| MCIC | MCIC Makerspace | Shining 3D | EinScan Pro 2X | Objects 15-80cm, 0.1mm resolution, tethered handheld | 1 |
| The Making Centre | The Makerspace | Artec 3D | Eva | Objects 20-50cm, 0.1mm Resolution, tethered handheld | 1 |
| The Making Centre | The Makerspace | Artec 3D | Leo | Objects 20-200cm, 0.2mm Resolution, standalone handheld | 1 |
| The Making Centre | The Makerspace | Artec 3D | Spider | Objects 5-50cm, 0.05mm Resolution, tethered handheld | 1 |
| The Making Centre | The Makerspace | Creality | CR-Scan Ferret Pro | Objects 15-200cm, 0.16mm Resolution, standalone handheld | 3 |
